Owner’s Manual: Display Console 21
Keypads
Use the keypads to enter your workout session selections, to
affect what appears on the display, and to establish your
incline and speed preferences.
Five distinct keypads exist on the display and are discussed
in this section:
• Lower Display keypad and the Selection keys
• User identification keys
• Navigational keypad in the center of the display
• PROGRAMS keypad
• Data keypad
Lower Display Keypad and the Selection Keys
Diagram 12: Lower Display keypad and the Selection keys
Left Selection Key: Every time you press this key the
the display reflects the amount of time elapsed since
you began your exercise session, or the time remaining,
or the cumulative number of calories burned. An LED
lights and indications which information is being
displayed. The TIME REMAINING display is lit when
you begin a program.
DISTANCE
PAC E
AVERAGE SPEED
TIME ELAPSED
TIME REMAINING
CALORIES
I
N
C
L
I
N
E
S
PE
E
D
QUICK
START
