Program Edit
18
OSC EG/LFO
OSC EG
Filter/Amp EG
HereyoucanadjustthesettingsforthefilterEGandamp
EGofoscillators1and2.
IntheFilter/AmpEGgroup,allfilterEGsandampEGsare
adjustedsimultaneously.In contrast,eachparameteris
adjustedindependentlyin theFltEQandAmpEGgroups.
AprogramcontainsthreeEGs:pitch,filter,andamp.These
respectivelyproducetime‐varyingchangeinthepitch,tone,
andvolume.
Attack Time (Filter/Amp EG Attack Time)
[–99...+99 (Rel, CC#73)]
ThisscalestheattacktimesoftheFilterandAmpEGs,along
withotherrelatedparameters.
Whenthevalueis+1ormore,thisalsoaffectstheAmpEG’s
StartandAttackLevels,StartLevelAMS,andAttackTime
AMS.
Betweenvaluesof+1and+25,theStartLe vel,StartLevel
AMS,andAtta
ckTimeAMSwillchangefromtheirpro‐
grammedvaluesto0.Overthesamerange,theAttackLevel
willchangefromitsprogrammedvalueto99.(“AMS(Alter‐
nateModulationSource)”onpage28)
Decay Time (Filter/Amp EG Decay Time)
[–99...+99 (Rel, CC#75)]
ThisscalesthedecayandslopetimesoftheFilterandAmp
EGs.
Sustain Level (Filter/Amp EG Sustain Level)
[–99...+99 (Rel, CC#70)]
ThisscalesthesustainlevelsoftheFilterandAmpEGs.
Release Time (Filter/Amp EG Release Time)
[–99...+99 (Rel, CC#72)]
ThisscalesthereleasetimesoftheFilterandAmpEGs.
Filter EG
TheseparametersadjustthefilterEGenvelopeforoscilla‐
tors1and2atthesametime.
Attack (Filter EG Attack Time) [–99...+99 (Rel)]
ThisscalestheattacktimesoftheFilterEGs.
Decay (Filter EG Decay Time) [–99...+99 (Rel)]
ThisscalesthedecayandslopetimesoftheFilterEGs.
Sustain (Filter EG Sustain Level) [–99...+99 (Rel)]
ThisscalesthesustainlevelsoftheFilterEGs.
Release (Filter EG Release Time) [–99...+99 (Rel)]
ThisscalesthereleasetimesoftheFilterEGs.
Amp EG
TheseparametersadjusttheampEGenvelopeforoscilla‐
tors1and2atthesametime.
Attack (Amp EG Attack Time) [–99...+99 (Rel)]
ThisscalestheattacktimesoftheAmpEGs.
Decay (Amp EG Decay Time) [–99...+99 (Rel)]
ThisscalesthedecayandslopetimesoftheAmpEGs.
Sustain (Amp EG Sustain Level) [–99...+99 (Rel)]
ThisscalesthesustainlevelsoftheAmpEGs.
Release (Amp EG Release Time) [–99...+99 (Rel)]
ThisscalesthereleasetimesoftheAmpEGs.
Pitch EG/LFO
TheseparametersadjustthepitchEGenvelopeforoscilla‐
tors1and2atthesametime.Youcanalsoadjustthedepth
oftheLFO1effect.
Attack (Pitch EG Attack Time) [–99...+99 (Rel)]
ThisscalestheattacktimeofthePitchEG.
Decay (Pitch EG Decay Time) [–99...+99(Rel)]
ThisscalesthedecayandslopetimesofthePitchEG.
Release (Pitch EG Release Time) [–99...+99 (Rel)]
ThisscalesthedecayandslopetimesofthePitchEG.
LFO1 Int (Pitch LFO1 Intensity)
[–99...+99 (Rel, CC#77)]
ThisscalestheeffectofLFO1onthePitch.
‐99removestheLFOmodulationentirely.+99meansmaxi‐
mummodulationinthesamedirection,positiveornega‐
tive,astheoriginalProgram.
Level
Time
Attack Time
Decay Time
Slope Time
Release Time
Attack Level
Start Level
Sustain Level
Break Level
note-on note-o
Release
Level
