Owner’s Manual: Display Console 19
More Information about the Upper
Display
The estimated cumulative number of calories burned and the
program profile appear during an exercise session in the
upper portion of the display. Your heart rate appears if you
are using the chest strap or touch-sensitive handrail grips.
Refer to Heart Rate Features.
In most programs, the incline setting affects the column
height in the program profile as shown in Diagram 7. The
profile raises or lowers according to which arrow key is
pressed.
Diagram 7: Column height in the program profile
More Information about the
Center Display
The center display presents the program name when you
select a program. During an exercise session, the center
display becomes a message bar showing additional
information depending on user selections and program
interludes. For more information about the selections that
can appear in the center display, refer to Changing Your
Workout Display Options.
More Information about the
Lower Display
The lower display provides information about your exercise
session. The two center windows automatically provide
information about your incline and speed. To choose the type
of information displayed in the left and right windows, press
the adjacent Selection key. The numbers that appear relate
to your workout statistics and are described below.
Note: If you choose to rest a book or magazine on the
display, you can still view these workout statistics.
-0.5 — -3
0.0 — 0.5
1 — 1.5
2 — 2.5
3 — 3.5
4 — 5.5
6 — 7.5
13 — 15
10 — 12.5
8 — 9.5
Column height Incline settings
