Product Owner’s Manual: Club Features 14
Viewing the Error Log
The first error log entry scrolls across the display. Up to ten error
codes can be retrieved. If there are no errors in the log, you will
see NO ERRORS displayed.
7. To view any additional error codes in the error log, use the arrow
keys. Each error code specifies when it occurred, listing the
odometer and hour meter values. Refer to Diagram 5.
Diagram 5: Error log
8. Copy the error code information to paper so you can provide it to
Customer Support if needed. Be sure to copy it exactly as
shown.
9. When you no longer need the information in the error log, press
QUICKSTART for at least four seconds to delete the error log.
Continue to maintain light pressure on the key until the message
OK appears. When the key is released, NO ERRORS appears in
the display, which indicates the error log has been deleted.
Important: You cannot retrieve the error log once you have
deleted it. You may want to resolve any issues you are
experiencing with the cycle before clearing the error log.
10.When you are ready, press SELECT or RESET to move to the
next display.
1: ER33 AT 12,345,678 rev 1,714 HOURS
Most recent error
Error code
The hour meter at the time
the error was detected.
Odometer reading at the
time the error occurred.
