Hardware Kit (not to scale)
Fasteners Quantity
(A) Hex head cap screw (5-inch) 2
(B) Washer (½-inch) 2
(C) Buttonhead screw (1³⁄₄-inch)
Important: You can discard the buttonhead
screws because they are not used in the
C846i/C842i Upright Cycle assembly.
4
2 — Rubber bib (D) 1 — ³⁄₁₆-inch hex key (E)
