8
13. Press Arm AssemblyÑLocate and open the parts
bag labeled ÒARM ASSEMBLY.Ó
Press a 2Ó Square Inner Cap (24) into the top of each
arm on the Press Frame (12). Lubricate the 1/2Ó x
9 1/2Ó Bolt (59). Slide the Cable Frame (57) in
between the arms of the Press Frame (12). Slide both
the Cable Frame and the Press Frame onto the Top
Frame (1) and align the holes in all three parts. Note:
This may be a tight fit. Attach the Cable Frame and
the Press Frame to the Top Frame with the 1/2Ó x
9 1/2Ó Bolt and a 1/2Ó Nylon Locknut (51). Do not
overtighten the Nylon Locknut; it must be easy to
pivot the Press Frame and Cable Frame.
13
Arm Assembly
12. Press a 2Ó Square Inner Cap (24) into the Butterfly
Seat Frame (11). Slide the Butterfly Seat Frame onto
the 5/16Ó x 2 1/2Ó Carriage Bolts (22) in the Butterfly
Base (8). Hand tighten a 5/16Ó Nylon Locknut (68)
onto each Carriage Bolt.
Insert two 5/16Ó x 2 3/4Ó Bolts (60) through the brack-
et on the Butterfly Seat Frame (11) and through the
holes in the Butterfly Upright (2). Orient the Support
Bracket (27) as shown in the drawing (the horizontal
arm of the bracket must be on the side facing away
from you in the drawing) and slide it onto the Bolts.
Hand tighten a 5/16Ó Nylon Locknut (68) onto each
Bolt. Tighten all Nylon Locknuts used in steps 6
through 12.
12
11. Slide the Press Seat Upright (37) onto the 5/16Ó x
2 1/2Ó Carriage Bolts (22) in the Press Base (4). Hand
tighten a 5/16Ó Nylon Locknut (68) onto each Carriage
Bolt. Do not tighten the Nylon Locknuts yet.
Insert two 5/16Ó x 2 1/2Ó Carriage Bolts (22) through
the bracket on the Press Seat Upright (37) and
through the holes in the Press Upright (3). Slide a
5/16Ó Flat Washer (53) onto each Bolt. Hand tighten a
5/16Ó Nylon Locknut (68) onto each Bolt. Do not
tighten the Nylon Locknuts yet.
11
10. Attach the upper ends of the Weight Guides (23) to
the welded bushing underneath the Top Frame (1)
with a 5/16Ó x 6 1/2Ó Bolt (89) and a 5/16Ó Nylon
Locknut (68). Tighten the Nylon Locknut fully.
10
3
22
68
22
11
68
60
24
60
2
59 Lubricate
51
12
24
22
68
Welded
Bushing
23
89
1
53
53
22
37
4
1
57
8
68
27
68
