13
28. Dis-assemble the second set of Pulley Plates (31).
Wrap the Butterfly Cable (97) around one of the
3 1/2Ó Pulleys (35) in the direction shown.
Attach the 3 1/2Ó Pulley (35) and a Cable Trap (44) to
the Pulley Plates (31) with a 3/8Ó x 2Ó Bolt (62) and a
3/8Ó Nylon Locknut (50).
28
27. Locate the Butterfly Cable (97). It is approximately
58Ó long and it has a closed loop on both ends.
Attach one end of the Butterfly Cable (97) to the indi-
cated bracket on the Left Butterfly Arm (81) with a
5/16Ó x 1Ó Bolt (48) and two 5/16Ó Nylon Jamnuts
(25). Do not overtighten the last Nylon Jamnut; it
must be easy to turn the Cable from side to side.
Wrap the Butterfly Cable (97) around a ÒVÓ-Pulley
(79) in the direction shown. Attach the ÒVÓ-Pulley and
a Long Cable Trap (84) to the bracket (see inset
drawing) on the Butterfly Upright (2) with a 3/8Ó x
2 1/4Ó Bolt (85) and a 3/8Ó Nylon Jamnut (78). Make
sure the Long Cable Trap is oriented as shown.
27
25
85
97
79
81
25
48
31
50
62
44
97
35
31
29. See drawing 29a. Wrap the Butterfly Cable (97)
around a ÒVÓ-Pulley (79) in the direction shown.
Attach the ÒVÓ-Pulley and a Long Cable Trap (84) to
the indicated bracket on the Butterfly Upright (2) with
a 3/8Ó x 2 1/4Ó Bolt (85) and a 3/8Ó Nylon Jamnut
(78). Make sure the Long Cable Trap is oriented
as shown.
See drawing 29b. Attach the end of the Butterfly
Cable (97) to the indicated bracket on the Right
Butterfly Arm (80) with a 5/16Ó x 1Ó Bolt (48) and two
5/16Ó Nylon Jamnuts (25). Do not overtighten the
last Nylon Jamnut; it must be easy to turn the
Cable from side to side.
29a
84
30. The Low Cable (72) is the only remaining Cable. It is
approximately 216Ó long and it has a ball on one end
and a closed loop on the other.
Locate the end of the Low Cable (72) with the ball.
Place the Low Cable in the groove of the Pulley (87)
that has been pre-attached to the Leg Lever (29).
While holding the Cable in place, mount a 5/16Ó x
2 1/2Ó Bolt (45) and a Plastic Spacer (83) in the indi-
cated hole. Secure the Bolt with a 5/16Ó Nylon Locknut
(68). Make sure the Low Cable is between the
Pulley and the Plastic Spacer. Do not overtighten
the Nylon Locknut; the Plastic Spacer must be
easy to rotate.
30
45
29
87
72
83
68
2
78
85
84
79
78
2
48
25
80
97
97
29b
