32. Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35)
in the direction shown.
Attach the Pulley (35) and a Cable Trap (44) to the
lowest of the two holes in the Pulley Plates (31) hang-
ing from the High Cable (73). Secure the Pulley and
Cable Trap with a 3/8Ó x 2Ó Bolt (62) and a 3/8Ó Nylon
Locknut (50).
Make sure the Cable Trap is oriented as shown
and that it is mounted between the Pulley Plates.
33. Remove the 3/8Ó Nylon Locknut (50) that was thread-
ed onto the 3/8Ó x 4 3/4Ó Bolt (65) in step 31.
Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35)
in the direction shown. Slide the Pulley and a Cable
Trap (44) onto the 3/8Ó x 4 3/4Ó Bolt (65). Secure the
Pulley with a 3/8Ó Nylon Locknut (50).
Make sure both Cable Traps attached to the 3/8Ó x
4 3/4Ó Bolt (65) are oriented as shown in this step
and in step 31.
32
33
31. Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35)
in the direction shown. Slide the Pulley and a Cable
Trap (44) onto a 3/8Ó x 4 3/4Ó Bolt (65). Slide the Bolt
into the indicated hole in the bracket on the Butterfly
Upright (2). Thread a 3/8Ó Nylon Locknut (50) a cou-
ple of turns onto the Bolt to prevent it from sliding out
during the following steps.
31
72
35
65
2
73
62
35
72
44
65
50
35
72
2
44
31
50
44
34. Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35)
in the direction shown. Attach the Pulley and a Cable
Trap (44) to the ÒIÓ-plates (31) hanging from the Short
Cable (97). Secure the Pulley and Cable Trap with a
3/8Ó x 2Ò Bolt (62) and a 3/8Ó Nylon Locknut (50).
Make sure the Cable Trap is oriented as shown
and that it is mounted between the Pulley Plates.
34
62
97
44
31
72
35
50
