12
25. Wrap the High Cable (73) around a 3 1/2Ó Pulley (35)
in the direction shown.
Attach the 3 1/2Ó Pulley (35) to the bracket on the Top
Frame (1) with a 3/8Ó x 2Ó Bolt (62) and a 3/8Ó Nylon
Locknut (50).
25
1
62
73
50
Bracket
35
26. Thread the bolt at the end of the High Cable (73) a
couple of turns into the top of the Weight Tube (77).
This is to prevent the High Cable from falling down
during the following steps. It will be permanently
attached in step 36.
26
73
77
24. Dis-assemble the pre-assembled Pulley Plates (31).
Wrap the High Cable (73) around one of the removed
3 1/2Ó Pulleys (35) in the direction shown.
Attach the 3 1/2Ó Pulley (35) and a Cable Trap (44) to
the Pulley Plates (31) with a 3/8Ó x 2Ó Bolt (62) and a
3/8Ó Nylon Locknut (50).
24
50
35
73
44
Holes
31
62
23. Remove the 3/8Ó Nylon Locknut (50) attached to the
3/8Ó x 5Ó Bolt (42) in step 19. Wrap the High Cable
(73) around a 3 1/2Ó Pulley (35) in the direction
shown.
Slide the 3 1/2Ó Pulley (35) and a Cable Trap (44)
onto the 3/8Ó x 5Ó Bolt (42) that was attached to the
Top Frame (1) in step 19. Secure the Pulley and
Cable Trap with a 3/8Ó Nylon Locknut (50). Note:
Before you tighten the 3/8Ó Nylon Locknut, make
sure the High Cable (73) rests in the grooves of
both of the Pulleys (35) attached to the Top Frame
(1). Make sure both Cable Traps (44) are oriented
as shown in this step and in step 19.
23
73
42
1
35
50
44
