Keyword Definition
...encapsulation
failed
Counts packets which could not be forwarded due to ARP
resolution failure. Dell Networking OS sends an arp request
prior to forwarding an IP packet. If a reply is not received,
Dell Networking OS repeats the request three times. These
packets are counted in encapsulation failed.
Rcvd:
...short packets The number of bytes in the packet are too small.
...bad length The length of the packet was not correct.
...no port
broadcasts
The incoming broadcast/multicast packet did not have any
listener.
...socket full The applications buffer is full and the incoming packet are
dropped.
The Dell Monitoring MIB provides access to the following statistics.
• IP Statistics: Bcast: Received: Object = f10BcastPktRecv, OIDs =
1.3.6.1.4.1.6027.3.3.5.1.1
• IP Statistics: Bcast: Sent: Object = f10BcastPktSent, OIDs =
1.3.6.1.4.1.6027.3.3.5.1.2
• IP Statistics: Mcast: Received: Object = f10McastPktRecv, OIDs =
1.3.6.1.4.1.6027.3.3.5.1.3
• IP Statistics: Mcast: Sent: Object = f10McastPktSent, OIDs =
1.3.6.1.4.1.6027.3.3.5.1.4
• ARP Statistics: Rcvd: Request: Object = f10ArpReqRecv, OIDs =
1.3.6.1.4.1.6027.3.3.5.2.1
• ARP Statistics: Rcvd: Replies: Object = f10ArpReplyRecv, OIDs =
1.3.6.1.4.1.6027.3.3.5.2.3
• ARP Statistics: Sent: Request: Object = f10ArpReqSent, OIDs =
1.3.6.1.4.1.6027.3.3.5.2.2
• ARP Statistics: Sent: Replies: Object = f10ArpReplySent, OIDs =
1.3.6.1.4.1.6027.3.3.5.2.4
• ARP Statistics: Sent: Proxy: Object = f10ArpProxySent, OIDs =
1.3.6.1.4.1.6027.3.3.5.2.5
Example
Dell#show ip traffic
Control Processor IP Traffic:
IP statistics:
Rcvd: 23857 total, 23829 local destination
0 format errors, 0 checksum errors, 0 bad hop count
0 unknown protocol, 0 not a gateway
0 security failures, 0 bad options
Frags: 0 reassembled, 0 timeouts, 0 too big
0 fragmented, 0 couldn't fragment
Bcast: 28 received, 0 sent; Mcast: 0 received, 0 sent
Sent: 16048 generated, 0 forwarded
21 encapsulation failed, 0 no route
ICMP statistics:
Rcvd: 0 format errors, 0 checksum errors, 0 redirects, 0
unreachable
0 echo, 0 echo reply, 0 mask requests, 0 mask replies, 0
