Column Heading Description
ospf 100 If routing protocols (OSPF, RIP) are configured and routes
are advertised, then information on those routes is
displayed.
Total 1388
active...
Displays the number of active and non-active routes and
the memory usage of those routes. If there are no routes
configured in the Dell Networking OS, this line does not
appear.
Example
Dell>show ip route summary
Route Source Active Routes Non-active Routes
connected 17 0
static 3 0
ospf 100 1368 2
Intra-area: 762 Inter-area: 1 External-1: 600 External-2: 5
Total 1388 2
Total 1388 active route(s) using 222440 bytes
Total 2 non-active route(s) using 128 bytes
Dell>
Related
Commands
show ip route — displays information about the routes found in the switch.
show ip traffic
View IP, ICMP, UDP, TCP and ARP traffic statistics.
S6000
Syntax
show ip traffic [all | cp | rp1 | rp2]
NOTE: These options are supported only on the E-Series.
Parameters
all (OPTIONAL) Enter the keyword all to view statistics from all
processors. If you do not enter a keyword, you also view all
statistics from all processors.
cp (OPTIONAL) Enter the keyword cp to view only statistics
from the Control Processor.
rp1 (OPTIONAL) Enter the keyword rp1 to view only the
statistics from Route Processor 1.
rp2 (OPTIONAL) Enter the keyword rp2 to view only the
statistics from Route Processor 2.
Command
Modes
EXEC Privilege
812
IPv4 Routing
