Dell#show hardware stack-unit 1 buffer-stats-snapshot unit 0
resource port 5 prio-group all
Stack-unit 1 unit 0 port 5 (interface te 1/4)
---------------------------------------------------------------
------------------------------------------------
PG# SHARED CELLS HEADROOM CELLS
---------------------------------------------------------------
------------------------------------------------
6 1000
5
7 3 0
show hardware stack-unit buffer-stats-snapshot (Total Buffer Information)
View the buffer statistics tracking resource information depending on the type of buffer information, such
as device-level details, port-level counters, queue-based snapshots, or priority group-level snapshot in
the egress and ingress direction of traffic. This command is supported on the S6000 platform.
Syntax
show hardware stack-unit stack-unit—number buffer-stats-
snapshot unit number buffer-info x
Parameters
stack-unit
stack-unit-
number
Unique ID of the stack unit to select a particular stack
member and then enter one of the following command
options to display a collection of data based on the option
entered. The range is from 0 to 11.
buffer-stats-
snapshot unit
number
Display the historical snapshot of buffer statistical values unit
Enter the keyword unit along with a port-pipe number,
then the keyword counters to display the counters on the
selected port-pipe. The range is from 0 to 0.
buffer-info buffer-info Displays total buffer information for a group,
where x can be one of the following:
• All - Displays ingress and egress device, port, and queue
snapshots
• Port {id |all} Displays both ingress and egress port-level
snapshot
• Port ingress {id |all} Displays ingress port-level snapshot
• Port egress {id |all) Displays egress port-level snapshot
• Port {id |all} queue {all} - egress queue-level snapshot for
both unicast and multicast packets
• Port {id |all} queue ucast {id | all} - egress queue-level
snapshot for unicast packets only
• Port {id |all} queue mcast {id | all} - egress queue-level
snapshot for multicast packets only
