Version Description
9.7(0.0) Introduced on the S6000–ON.
9.4.(0.0) Added support for VRF.
9.0.2.0 Introduced on the S6000.
8.3.19.0 Introduced on the S4820T.
8.3.11.1 Introduced on the Z9000.
8.3.7.0 Introduced on the S4810.
7.8.1.0 Introduced on the S-Series.
7.7.1.0 Introduced on the C-Series.
Usage
Information
The following describes the show ip bgp paths community command shown
in the following example.
Field Description
Address Displays the internal address where the path attribute is
stored.
Hash Displays the hash bucket where the path attribute is stored.
Refcount Displays the number of BGP routes using these
communities.
Community Displays the community attributes in this BGP path.
Example
Dell#show ip bgp paths community
Total 2 communities
Refcount Community
1 NO-ADVERTISE
1 200:1 1000:1 3000:1
show ip bgp peer-group
Allows you to view information on the BGP peers in a peer group.
S6000
Syntax
show ip bgp [vrf vrf-name] [ipv4 {multicast | unicast} | ipv6
unicast] peer-group [peer-group-name [detail | summary]]
Parameters
vrf vrf-name (OPTIONAL) Enter the keyword vrf to view information on
BGP peers in a peer group corresponding to that VRF.
NOTE: You can use this attribute to view information on
BGP peers in a peer group that correspond to either a
default or a non-default VRF.
Border Gateway Protocol
445
