Commander GP User Guide
Issue code: gpxu2
D-18 Menu 0 Parameters
0.29 EUR> Current-loop integral gain
USA> Terminal-29
destination selector
Applicable to Macros...
01234567
European configuration
RW Uni
0 ~ 30 000 40
Do not adjust this parameter.
USA configuration
RW Uni R P
0.00 ~ 20.50 1.41 Menu.
parameter
Use 0.29 to change the function of the digital input
on terminal 29.
The default setting (1.41) gives LOCAL/REMOTE
switching.
When 0.27 Sequencing mode selector is set at 0, it is
essential that you set 0.29 at 6.34. This makes
terminal 29 function as a stop input
(RUN PERMIT / STOP).
0.29 Motorized potentiometer rate
RW Uni
0 ~ 250 20 s
Applicable to Macros...
01234567
Enter the required time for the
motorized-potentiometer output to change by
100%.
0.28 Analog input 2 (PID reference)
scaling
0.29 Analog input 3 (PID feedback)
scaling
RW Uni
0 ~ 4 1
Applicable to Macros...
0123
567
If required, change the scaling of the PID reference
and feedback inputs by entering appropriate values
in these parameters.
0.29 Analog input 1
(Torque reference) scaling
0.30 Analog input 2
(Frequency reference) scaling
RW Uni
0 ~ 4 1
Applicable to Macros...
0123
567
If required, change the scaling of the torque
reference and frequency reference inputs by
entering appropriate values in these parameters.
0.30 FWD/REV key enable
RW Bit
0 ~ 1 0
Applicable to Macros...
0123
567
The Drive is supplied with the key disabled.
To enable this key, set 0.30
FWD/REV enable at 1.
