Table 5-7. Other Replacement Assemblies (continued)
Ref. Desig. Agilent Model Agilent Part Number Description
All 4040-1954 Window, display
6023A 5020-8847 Trim strip
All 5041-8803 Trim strip, top
All 5001-0540 Trim, side 7in
All 5021-8417 Frame front
All 5041-8801 Foot
All 5041-8819 Retainer, strap handle
All 5041-8820 Retainer, strap handle
All 5041-0309 Key cap, quarter
All 5062-3703 Assembly, handle strap
All 7120-1254 Nameplate
All 7120-8572 Canadian Standards Association Label (ref.
rear panel)
All 7121-2527 Metric and Inch Label (ref. rear panel)
All 7121-2794 Serial Identification Label (ref. rear panel)
6023A 06023-00016 Chassis
6028A 06023-00001 Chassis
All 06023-00020 Cover, top
All 06023-00022 Cover, bottom
6023A 06023-00004 Bracket, upper
6023A 06023-00014 Panel, sub
6023A 06023-00018 Sub panel, front
6023A 06023-00007 Bus bar, negative
6023A 06023-00008 Bus bar, positive
All 06023-00009 Cover, bar block
6023A 06023-00010 Cover,(top plate screened)
6028A 06023-00026 Cover,(top plate screened)
6023A 06023-00019 Rear panel, screened
6028A 06023-00011 Rear panel, screened
All 06028-00021 Front-panel, screened
All 06023-81003 Line Voltage Label (ref. rear panel) 28480
6023A 06023-90001 Operating and Service manual
6028A 06028-90001 Operating and Service manual
6023A 1990-0521 Cover, terminal block
Option 220 (220V Operation)
All 2110-0055 Fuse 4A 250V (rear chassis)
All 2110-0383 Fuse 8A 250V (rear chassis)
All 7120-8572 Label, info
All 06023-81001 Label, info
Option 240 (240V Operation)
All 2110-0055 Fuse 4A 250V (rear chassis)
All 2110-0383 Fuse 8A 250V (rear chassis)
All 7120-8572 Label, info
All 06023-81002 Label, info
