Table 5-5. A3 Front-Panel Board Parts List
Ref. Desig. Agilent Model Agilent Part Number Description
R68 All 0698-6362
Resistor, fixed film 1K
Ω 0.1% 1/8W
R69 All 0698-6343
Resistor, fixed film 9K
Ω 0.1% 1/8W
R71 6023A 0698-6363
Resistor, fixed film 40K
Ω 0.1% 1/8W
R71 6028A 0698-8861
Resistor, fixed film 6.66K
Ω 0.1% 1/8W
R72 6023A 0698-7353
Resistor, fixed film 19K
Ω 1% 1/8W
R72 6028A 0698-4493
Resistor, fixed film 34K
Ω 1% 1/8W
R73 6023A 0757-0280
Resistor, fixed film 1K
Ω 1% 1/8W
R73 6028A 0698-3476
Resistor, fixed film 6.00K
Ω 1% 1/8W
R74 All 0683-1025
Resistor, fixed film 1K
Ω 5% 1/4W
R75 All 0683-3025
Resistor, fixed composition 3K
Ω 5% 1/4W
R77 All 0757-0458
Resistor, fixed film 51.1K
Ω 1% 1/8W
R78 All 0698-3159
Resistor, fixed film 26.1K
Ω 1% 1/8W
R79 All 0757-0441
Resistor, fixed film 8.25K
Ω 1% 1/8W
R80 All 0757-0438
Resistor, fixed film 5.11K
Ω +1% 1/8W
R81 All 0683-5135
Resistor, fixed composition 51K
Ω ± % 1/4W
R82 All 0683-1025
Resistor, fixed composition 1K
Ω 5% 1/4W
R83 All 0683-5125
Resistor, fixed composition 5.1K
Ω ~5% 1/4W
R84 All 0683-1025
Resistor, fixed composition 1K
Ω 5% 1/4W
R85 All 0757-0280
Resistor, fixed film 1K
Ω 1% 1/8W
R86 All 0698-5808
Resistor, fixed film 4K
Ω 1% 1/8W
R87 6023A 0698-3201
Resistor, fixed film 80K
Ω 1% 1/8W
R87 6028A 0757-0449
Resistor, fixed film 20K
Ω 1% 1/8W
R88 6023A 0757-0449
Resistor, fixed film 20K
Ω 1% 1/8W
R88 6028A 0757-0453
Resistor, fixed film 30.1K
Ω 1% 1/8W
R89 All 0683-5135
Resistor, fixed composition 51K
Ω 5% 1/4W
R90 All 0757-0199
Resistor, fixed film 21.5K
Ω + 1% 1/4W
R91 All 0683-5235
Resistor, fixed composition 51K
Ω 5% 1/4W
R92,93 All 0757-0452
Resistor, fixed film 27.4K
Ω 1% 1/8W
S1,2 All 5060-9436 Switch lighted pusbutton
U1 All 1826-0502 IC switch analog quad
U2 All 1826-0493 IC op amp lo-bias hi-impedance
U3 All 1826-0346 IC op amp dual general purpose
U4,5 All 1826-0876 IC A/D CMOS 3-1/2 DGT
U6 All 1820-1144 IC gate TTL LS NOR quad
U7 All 1826-0502 IC switch analog quad
U9 All 1826-0138 IC comparator GP quad
VR1 All 1902-3092 Diode zener 4.99V 2%
VR2 All 1902-0064 Diode zener 7.5V 5%
W4 All 7175-0057 Wire 22 AWG
W7 6028A 7175-0057 Wire 22 AWG
W8 6023A 7175-0057 Wire 22 AWG
W11 All 7175-0057 Wire 22 AWG
