Table 5-3. A1 Main Board Parts List
Ref. Desig. Agilent Model Agilent Part Number Description
ELECTRICAL PARTS
Al 6023A 06038-60021 Main Board Assembly
Al 6028A 06038-61021 Main Board Assembly
C1 All 0160-4962
Capacitor, 1
µF + 10% 50Vac
C2,3 All 0180-3426
Capacitor, 590
µF + 50-10% 400V
C4 All 0180-3427
Capacitor, 300
µF + 50-10% 200V
C5 All 0160-4962
Capacitor, l
µF + 10% 50V
C6,7 All 0160-5933
Capacitor, 0.022
µF + 10% 1500V
C8-10 6023A 0180-3425
Capacitor, 5500
µF +50-10% 40V
C8-10 6028A 0160-3548
Capacitor, 1700
µF 75V
C11-12 6023A 0160-5377
Capacitor, 2.2
µF +10% 6.3V
C11-12 6028A 0160-6167
Capacitor, 2.2
µF 63V
C13,14 6023A 0160-7731
Capacitor, 0.22
µF + 10% 1500V
C13,14 6028A 0160-5933
Capacitor, 0.022
µF + 10% 1500V
C15,16 All 0160-4355
Capacitor, 0.01
µF + 10% 250V
C17 6023A 0160-5422
Capacitor, 0.047
µF + 20% 50V
C17 6028A 0160-4834
Capacitor, 0.047
µF + 20% 50V
C20,21 All 0180-3428
Capacitor, 1000
µF 50V
C22,23 All 0160-4439
Capacitor, 4700
µF 20% 250V
C24,25 6028A 0160-4281
Capacitor, 2200
µF 20% 250V
C26 6028A 0160-4323
Capacitor, 0.047
µF 20% 250V
CR1-4 6023A 1901-1199 Diode power rectifier 600V 3A
CR1 6028A 1901-1087 Diode power rectifier 600V 3A
CR2 6028A 1901-0759 Diode power rectifier 600V 3A
CR3 6028A 1901-1087 Diode power rectifier 600V 3A
CR4 6028A 1901-0759 Diode power rectifier 600V 3A
CR6, 7 All 1901-0731 Diode power rectifier 600V 3A
CR8, 9 All 1901-0050 Diode power rectifier 600V 3A
CR13, 15 All 1901-0731 Diode power rectifier 600V 3A
F2 All 2110-0007 Fuse 1A 250V
F3 6028A 2110-0763 Fuse 1/4A 125V
J1 All 1251-5927 Connector, 26-contact
J2 All 1251-5384 Connector, 3-contact
J3 All 1251-8676 Connector, 5-contact
K1 All 0490-1417 Relay, DPST
L1 All 06024-80094 Choke RFI 3A (magnetic core 9170-0721)
L3 6023A 5080-1981
Choke, output 0.5
µH
L3 6028A 9140-0987
Choke 3
µH
Q1 6028A 1854-0087 Transistor NPN SI
Q2 6028A 1854-0799 Transistor NPN SI TIP41C
R1 All 0811-3667
Resistor 20
Ω 5% 7W
R2 All 0811-1865
Resistor 2k
Ω 10% 5W
R3 6023A 5080-2007 Sensing resistor 0.005
R4 All 0683-1025
Resistor 1K
Ω 5% 1/4W
R5 6023A 8151-0013 Wire, 22 AWG
R5 6028A 7175-0057 Wire, tinned copper, AWG 22
R6 All 0683-1025
Resistor 1K
Ω 5% 1/4W
R7 6028A 0699-1210
Resistor 80K
Ω 0.1% 0.1W
R8-10 6023A 8151-0013 Wire, 22 AWG
