56
Table 5-3. A1 Main Board Parts List (continued)
Ref. Desig. Agilent Model Agilent Part Number Description
R8 6028A 0699-0118
Resistor 20
Ω 0.1% 0.1W
R9 6028A 7175-0057 Wire tinned copper AWG 22
R10 6028A 0698-6359
Resistor 80K
Ω 0.1% 1/8W
R11 All 0698-6322
Resistor 4K
Ω 0.1% 1/8W
R12 All 0698-8695
Resistor 36K
Ω 0.1% 1/8W
R14 6023A 0698-3572
Resistor 60.4
Ω 1% 1/8W
R15 6023A 8151-0013 Wire 22 AWG
R15 6028A 0757-0270
Resistor 249K
Ω 1% 1/4W
R17,18 All 0683-1005
Resistor 10
Ω 5% 1/4W
R19 All 0683-1055
Resistor 1M
Ω 5% 1/4W
R20,21 All 0811-1867
Resistor 15K
Ω 5% 5W
R22.23 All 0686-1065
Resistor 10M
Ω 5% 1/2W
R24,25 All 0686-1035
Resistor 10K
Ω 5% 1/2W
R26 All 0683-3315
Resistor 330
Ω 5% 1/4W
R27A,28B 6028A 0811-3823
Resistor 0.1
Ω 5% 20W
R29 6028A 0686-3335
Resistor 33K
Ω 5% 1/2W
R30 6028A 0811-1865
Resistor 2K
Ω 1% 5W
R31 6028A 0812-0098
Resistor 135
Ω 5% 5W
R32 6028A 0683-1035
Resistor 10K
Ω 5% 1/4W
R33 6028A 0683-4745
Resistor 470
Ω 5% 1/4W
R34 6028A 0683-2035
Resistor 20K
Ω 5% 1/4W
S1 6023A 3101-0402 Switch DPST rocker (mounted on front-
panel)
S2 All 3101-1914 Switch 2-DPDT slide
S4 All 3101-2046 Switch DPDT slide
T1 6023A 5080-1978 Transformer, power
T1 6028A 06038-80090 Transformer, power
T2 All 9170-1264 Core magnetic (used with primary wire
06023-80004)
T3 All 9100-4864 Transformer bias
T4 All 5080-1984 Choke line 2mH
TP1, 2 All 1251-5613 Connector single contact
U1 All 1906-0006 Rectifier bridge 400V 1A
VR1, 2 6028A 1902-1377 Diode zener 6.19V 2%
W1, 2 All 06023-80003 Jumper output 10 AWG
XA2P1 All 1251-8665 Connector, 30-contact
XA2P2 All 1251-8667 Connector, 20 contact
XA4P1, 2 All 1251-8806 Connector, DIN 32-contact
MECHANICAL PARTS
6028A 1480-0552 Pin, escutcheon (L1)
6028A 0380-1489 Snap-in-spacer
6028A 2110-0269 Fuseholder, clip type F2
6028A 0360-2190 Jumper, locai sensing (2)
6028A 0360-1833 Barrier block, 6-position
6023A 0515-0964 screw
6023A 2190-0586 washer, lock
6023A 3050-0893 washer, flat
