page 15
COMMERCIAL PRODUCTS DIVISION
Important: With the handrails attached, the width of the treadmill is 33½
inches (85 cm). It will not fit through a standard 32-inch doorway.
10. Prepare the unit for handrail installation. Diagram 9. For an easier installation,
raise the incline to its maximum height by taking the following steps:
a. Plug the treadmill into a power outlet and turn the unit ON.
b. Stand to the side of the treadmill and press QUICKSTART (see inset).
After a few seconds, the running belt begins moving.
c. Press the INCLINE ▲ key until the display shows an incline of 15 percent.
d. Once the lift stops moving and the display indicates 15 percent, press
the Stop (red) button and turn power switch OFF.
11. Remove the lower handrail clamp. Diagram 10. To prepare the unit for
handrail installation, remove the four fasteners securing the lower handrail
clamp. Use the hex key provided.
Diagram 10
Remove the
lower handrail
clamp.
Loosen and
remove the four
handrail clamp
screws.
Lower handrail
clamp
Diagram 9
Raise the
incline.
Incline lift
Side rail
QUICKSTART
TM
key
