page 12
COMMERCIAL PRODUCTS DIVISION
3. Move the treadmill. Diagram 3. To properly lift the rear end and roll it on its
front wheels, review Diagram 3. To avoid injury to yourself or damage to the
unit, ask for help in placing the treadmill where you plan to use it.
4. Remove the shipping fasteners from the front panel. Diagram 4. With
the supplied hex key and a ½-inch box end wrench, loosen and remove the
four bolts, washers and nuts on the front panel. These fasteners are used
during shipping to hold the front panel in place. Discard the fasteners.
5. Remove any tape or wire ties that secure the display cable to the side of
the unit.
CAUTION: To avoid damage to the display cable, read the following steps
carefully. Damage to the cable due to improper assembly is not covered
by the Precor limited warranty.
Diagram 3
Lift the unit by
placing hands
on opposite
sides of the rear
cross brace
found under
treadmill’s
running belt.
Lift the rear of the
unit and roll it to
its assembly
location.
Rear cover of unit
Diagram 4
Remove the
shipping
fasteners from
the front plate.
Front panel
Shipping
fasteners found
on right and left
sides of the front
panel.
