page 23
COMMERCIAL PRODUCTS DIVISION
R
E
S
I
S
T
A
N
C
E
C
O
U
R
S
E
C
H
A
N
G
E
Diagram 11
C846 Display
If a heart rate is
detected, it is
displayed in this
window.
SmartRate
®
bar graph
Banner and course
profile display
(LED matrix).
Workout statistics display
(alphanumeric).
Numeric keys can be
used to answer
prompts and select
resistance levels in a
course.
Touch-sensitive keys
(used to input or select
data and control the
workout session)
Change keys let you
choose what informa-
tion to display.
During course
selection, the course
number appears.
UPPER DISPLAY
The Precor banner and course profiles appear in the large center display (LED matrix).
Always start a workout at the Precor banner. During workouts, the course profile
appears in the center display and corresponds to the course that the user selects. As
a user proceeds through a workout, a blinking column indicates his or her position.
INFORMATIONAL DISPLAYS PRIOR TO SHUTDOWN
The C846 saves its battery charge by moving into a shutdown mode. Whenever
PEDAL FASTER appears on the display, the heart rate, SmartRate
®
and course
indicators turn off. If the user does not maintain a pedal speed of 20 revolutions
per minute, then a thirty-second shut down process begins.
When twenty-eight seconds remain, the upper display appears blank and all key
presses are ignored except RESET. The touch-sensitive heart rate features are
also ignored. If no pedaling occurs in the next eight seconds, a row of dots (that
correspond to the number of seconds remaining before the C846 shuts off)
appears in the upper display.
If the C846 is connected to a CSAFE master device, a slightly different scenario
occurs. When the number of seconds remaining before the C846 shuts off equals
ten seconds (instead of eight), the workout session ends. RESETTING appears
in the lower display while the C846 disconnects from the CSAFE master device.
All key presses are ignored. Pedaling has no effect on the display.
