COMMERCIAL PRODUCTS DIVISION
CAUTION: Always make sure that the seat is securely in place before a
user sits on the cycle.
On the C846 Recumbent, you need to sit on the seat, pull up on the seat
adjustment handle and use your legs to move the seat along the center post.
If you notice that the seat rocks from side to side, you’ll need to realign the
center wheel that runs inside the center post. Refer to the instructions in the
Maintenance
section of this manual.
9. Level the unit. Diagram 7. Once the base and upright assembly is com-
plete, you’ll need to check the unit’s stability. The unit has adjustable feet
that can help level the unit plus or minus ¹⁄₄ - inch. If necessary, rotate the
level adjusters to stabilize the unit. Turning the level adjustors clockwise,
raises the crossbar. The adjustable feet are on the front of the Upright C846
and the rear of the Recumbent C846.
Diagram 6
Adjusting the seat on the
C846 Recumbent.
Seat adjustment handle
Accessory tray
Diagram 7
Leveling the unit.
Level adjustor
Crossbar
Heart rate touch-
sensitive grips
You’ve completed the assembly for the C846. Please test the heart rate display and
review the remaining sections of this manual before allowing user’s access to the unit.
