-36-
79 MOTION_TH_DL, 8/12/8/8/8/12/8/8 0 ~ 255 091
80 MOTION_WEIGHT_0, 9/9/9/9/9/9/9/9 0 ~ 15 092
81 MOTION_WEIGHT_1, 8/8/8/8/8/8/8/8 0 ~ 15 093
82 MOTION_WEIGHT_2, 7/7/7/7/7/7/7/7 0 ~ 15 094
83 MOTION_WEIGHT_3, 6/6/6/6/6/6/6/6 0 ~ 15 095
84 MOTION_WEIGHT_4, 5/5/5/5/5/5/5/5 0 ~ 15 096
85 MOTION_WEIGHT_5, 4/4/4/4/4/4/4/4 0 ~ 15 097
86 MOTION_WEIGHT_6, 3/3/3/3/3/3/3/3 0 ~ 15 098
87 MOTION_WEIGHT_7, 2/2/2/2/2/2/2/2 0 ~ 15 099
88 MOTION_WEIGHT_8, 1/1/1/1/1/1/1/1 0 ~ 15 100
89 MOTION_SUM_0, 20/20/0/0/20/20/0/0 0 ~ 1023 101
90 MOTION_SUM_1, 32/32/9/9/32/32/9/9 0 ~ 1023 103
91 MOTION_SUM_2, 86/86/0/0/86/86/0/0 0 ~ 1023 105
92 MOTION_SUM_3, 110/110/63/63/110/110/63/63 0 ~ 1023 107
93 PEAK_V_LPF_SEL, 1 0 or 1 109 (reg 7)fix
94 PEAK_V_CORR, 4 0 ~ 255 110
95 PEAK_V_GAIN, 6 0 ~ 63 111
96 PEAK_V_GAIN_TH, 0 0 ~ 255 112
97 PEAK_V_GAIN_SLOPE, 0 0 ~ 7 113
98 PEAK_V_MAX, 255 0 ~ 255 114
99 TI_Y_TH_MIN, 0 0 ~ 255 115
100 TI_Y_TH_MAX, 0 0 ~ 255 116
101 TI_Y_CORR, 0 0 ~ 255 117
102 TI_Y_GAIN, 0 0 ~ 63 118
103 TI_Y_GAIN_TH, 0 0 ~ 255 119
104 TI_Y_GAIN_SLOPE, 0 0 ~ 7 120
105 TI_Y_GAIN_SEL, 0 0 ~ 7 121
106 TI_C_TH_MIN, 0 0 ~ 255 122
107 TI_C_TH_MAX, 0 0 ~ 255 123
108 TI_C_CORR, 0 0 ~ 255 124
109 TI_C_GAIN, 0 0 ~ 63 125
110 TI_C_GAIN_TH, 0 0 ~ 255 126
111 TI_C_GAIN_SLOPE, 0 0 ~ 7 127
112 TI_C_GAIN_SEL, 0 0 ~ 7 128
113 PEAK_H_BPF_SEL, 2/0 0 ~ 3 129(reg 8)NTSC,PAL / except NT,PAL
114 PEAK_H_CORR, 4/4 0 ~ 255 130
115 PEAK_H_GAIN, 6/0 0 ~ 63 131
116 PEAK_H_GAIN_TH, 0/0 0 ~ 255 132
117 PEAK_H_GAIN_SLOPE, 3/0 0 ~ 7 133
118 PEAK_H_GAIN_SEL, 1/0 0 ~ 3 134
119 PEAK_H_MAX, 255/255 0 ~ 255 135
120 Y2G, 256/256 0 ~ 1023 136/137(reg 9)NTSC,PAL,480p,575p / 1035i,1080i,1080i50,720p
121 CB2G, 936/976 0 ~ 1023 138/139
122 CR2G, 841/904 0 ~ 1023 140/141
123 Y2B, 256/256 0 ~ 1023 142/143
124 CB2B, 454/475 0 ~ 1023 144/145
125 CR2B, 0/0 0 ~ 1023 146/147
126 Y2R, 256/256 0 ~ 1023 148/149
127 CB2R, 0/0 0 ~ 1023 150/151
128 CR2R, 359/403 0 ~ 1023 152/153
129 G_Y_OUT_OS, 0 0 ~ 255 154 (reg A)fixed
130 G_Y_OUT_MIN, 0 0 ~ 255 155
131 G_Y_OUT_DC, 16 0 ~ 255 156
132 G_Y_OUT_MAX, 255 0 ~ 255 157
133 B_CB_OUT_OS, 0 0 ~ 255 158
134 B_CB_OUT_MIN, 0 0 ~ 255 159
135 B_CB_OUT_DC, 16 0 ~ 255 160
136 B_CB_OUT_MAX, 255 0 ~ 255 161
137 R_CR_OUT_OS, 0 0 ~ 255 162
138 R_CR_OUT_MIN, 0 0 ~ 255 163
139 R_CR_OUT_DC, 16 0 ~ 255 164
140 R_CR_OUT_MAX, 255 0 ~ 255 165
141 CINEMA_START_H, 0/0/0 0 ~ 255 166 (reg B)IP-ON=NTSC /except IP-ON=NT / IP-OFF
142 CINEMA_SIZE_H, 160/0/0 0 ~ 255 167
143 CINEMA_START_V, 1/0/0 0 ~ 255 168
144 CINEMA_SIZE_V, 60/0/0 0 ~ 255 169
145 CINEMA_MOTION_TH, 16/0/0 0 ~ 255 170:limited value is 10 (cinema identify sense)
146 CINEMA_DET_TH, 384/0/0 0 ~ 65535 171:1024 limited value
147 CINEMA_DET_FIELD, 7/0/0 0 ~ 7 173
148 CINEMA_CTL_SWAP, 20/0/0 0 ~ 31 174
149 CINEMA_CTL_Y, 0/1/1 0 or 1 175-1
150 CINEMA_CTL_C, 1/1/1 0 or 1 175-0
151 EXT_CINEMA_DET, 0/0/0 0 or 1 176-2
152 EXT_CINEMA_MODE, 0/0/0 0 or 1 176-1
153 EXT_CINEMA_SWAP, 0/0/0 0 or 1 176-0
Group:21 MB40C348
0 v_amp 1 0 or 1 adr0-2
1 dsel 1 0 or 1 adr0-1
2ce00 or 1 adr0-0
3 counter_w 64 0 ~4095 adr1,adr2(3-0)
4 adc_out 0 0 or 1 adr3-7
5 hsync_pol 1 0 or 1 adr3-6
6 clk_delay 0 0 ~ 63 adr3(5-0)
Electrical Adjustments
No. Adjustment Item Initial Value Range Input source / Description
