-34-
46 HINOR_VALU_FAN2_MIN 95 0~255 FAN2 control minimum value, HighLand Normal
47 HINOR_VALU_FAN2_MAX 138 FAN2 control maximum value, HighLand Normal
48 HINOR_VALU_FAN3_MIN 90 FAN3 control minimum value, HighLand Normal
49 HINOR_VALU_FAN3_MAX 115 FAN3 control maximum value, HighLand Normal
50 HIECO_TEMP_FAN1_MIN 22 FAN1 temperature to start the control, HighLand Eco
51 HIECO_TEMP_FAN1_MAX 32 FAN1 temperature to end the control, HighLand Eco
52 HIECOTEMP_FAN2_MIN 22 0~255 FAN2 temperature to start the control, HighLand Eco
53 HIECO_TEMP_FAN2_MAX 32 FAN2 temperature to end the control, HighLand Eco
54 HIECO_TEMP_FAN3_MIN 22 FAN3 temperature to start the control, HighLand Eco
55 HIECO_TEMP_FAN3_MAX 32 FAN3 temperature to end the control, HighLand Eco
56 HIECO_VALU_FAN1_MIN 75 FAN1 control minimum value, HighLand Eco
57 HIECO_VALU_FAN1_MAX 110 FAN1 control maximum value, HighLand Eco
58 HIECO_VALU_FAN2_MIN 85 0~255 FAN2 control minimum value, HighLand Eco
59 HIECO_VALU_FAN2_MAX 100 FAN2 control maximum value, HighLand Eco
60 HIECO_VALU_FAN3_MIN 70 FAN3 control minimum value, HighLand Eco
61 HIECO_VALU_FAN3_MAX 90 FAN3 control maximum value, HighLand Eco
62 CLNOR_TEMP_FAN1_MIN 28 FAN1 temperature to start the control, Ceiling Normal
63 ClNOR_TEMP_FAN1_MAX 36 FAN1 temperature to end the control, Ceiling Normal
64 CLNOR_TEMP_FAN2_MIN 28 0~255 FAN2 temperature to start the control, Ceiling Normal
65 CLNOR_TEMP_FAN2_MAX 36 FAN2 temperature to end the control, Ceiling Normal
66 CLNOR_TEMP_FAN3_MIN 28 FAN3 temperature to start the control, Ceiling Normal
67 CLNOR_TEMP_FAN3_MAX 36 FAN3 temperature to end the control, Ceiling Normal
68 CLNOR_VALU_FAN1_MIN 90 FAN1 control minimum value, Ceiling Normal (0:Fan voltage 0V, 255:Fan voltage 25.5V)
69 CLNOR_VALU_FAN1_MAX 135 FAN1 control maximum value, Ceiling Normal
70 CLNOR_VALU_FAN2_MIN 80 0~255 FAN2 control minimum value, Ceiling Normal
71 CLNOR_VALU_FAN2_MAX 135 FAN2 control maximum value, Ceiling Normal
72 CLNOR_VALU_FAN3_MIN 70 FAN3 control minimum value, Ceiling Normal
73 CLNOR_VALU_FAN3_MAX 105 FAN3 control maximum value, Ceiling Normal
74 CLECO_TEMP_FAN1_MIN 28 FAN1 temperature to start the control, Ceiling Eco
75 CLECO_TEMP_FAN1_MAX 36 FAN1 temperature to end the control, Ceiling Eco
76 CLECOTEMP_FAN2_MIN 28 0~255 FAN2 temperature to start the control, Ceiling Eco
77 CLECO_TEMP_FAN2_MAX 36 FAN2 temperature to end the control, Ceiling Eco
78 CLECO_TEMP_FAN3_MIN 28 FAN3 temperature to start the control, Ceiling Eco
79 CLECO_TEMP_FAN3_MAX 36 FAN3 temperature to end the control, Ceiling Eco
80 CLECO_VALU_FAN1_MIN 55 FAN1 control minimum value, Ceiling Eco
81 CLECO_VALU_FAN1_MAX 120 FAN1 control maximum value, Ceiling Eco
82 CLECO_VALU_FAN2_MIN 70 0~255 FAN2 control minimum value, Ceiling Eco
83 CLECO_VALU_FAN2_MAX 100 FAN2 control maximum value, Ceiling Eco
84 CLECO_VALU_FAN3_MIN 55 FAN3 control minimum value, Ceiling Eco
85 CLECO_VALU_FAN3_MAX 75 FAN3 control maximum value, Ceiling Eco
86 FAN1_ADJUST_VOLT_MIN 27 FAN1 DAC adjustment value at minimum drive voltage ✻ FAN Voltage Adjustment [FAN1]
87 FAN1_ADJUST_VOLT_MAX 249 FAN1 DAC adjustment value at maximum drive voltage ✻ FAN Voltage Adjustment [FAN1]
88 FAN2_ADJUST_VOLT_MIN 27 FAN2 DAC adjustment value at minimum drive voltage ✻ FAN Voltage Adjustment [FAN2]
89 FAN2_ADJUST_VOLT_MAX 249 FAN2 DAC adjustment value at maximum drive voltage ✻ FAN Voltage Adjustment [FAN2]
90 FAN3_ADJUST_VOLT_MIN 27 FAN3 DAC adjustment value at minimum drive voltage ✻ FAN Voltage Adjustment [FAN3]
91 FAN3_ADJUST_VOLT_MAX 249 FAN3 DAC adjustment value at maximum drive voltage ✻ FAN Voltage Adjustment [FAN3]
92 CL_FAN_TEMP_A_WARNING 39
93 CL_FAN_TEMP_B_WARNING 47
94 CL_FAN_TEMP_C_WARNING 67 0~255
95 CL_FAN_TEMP_BÅ|Ç`_WARNING 23
96 CL_FAN_TEMP_CÅ|Ç`_WARNING 39
97 HI_FAN_TEMP_A_WARNING 35
98 HI_FAN_TEMP_B_WARNING 49
99 HI_FAN_TEMP_C_WARNING 67
100
HI_FAN_TEMP_BÅ|Ç`_WARNING
29
101 HI_FAN_TEMP_CÅ|Ç`_WARNING 48
Group:12 PC Real / AV Cinema
0 PC Real Contrast 32 0 ~ 63
1 PC Real Brightness 32 0 ~ 63
2 PC Real Red 32 0 ~ 63
3 PC Real Green 30 0 ~ 63
4 PC Real Blue 29 0 ~ 63
5 PC Real Gamma 8 0 ~ 15
6AV Cinema Contrast 32 0 ~ 63
7AV Cinema Brightness 32 0 ~ 63
8AV Cinema Color 32 0 ~ 63
9AV Cinema Tint 32 0 ~ 63
10 AV Cinema Red 32 0 ~ 63
11 AV Cinema Green 30 0 ~ 63
12 AV Cinema Blue 29 0 ~ 63
13 AV Cinema Sharpness 15 0 ~ 31
14 AV Cinema Gamma 8 0 ~ 15
15 AV Cinema N.R. 1 0 or 2
16 AV Cinema PROGRESSIVE 1 0 or 1
Group:20 IP Conversion
0 IMAGE_IN_FUNC_POL 0/0/0/0/0/0/0/0/0 0 or 1 000-b4 (reg 0)NTSC/PAL/480p/575p/1035i/1080i,1080i50/720p/480i/575i
1 IMAGE_IN_HD_SEL 1/1/1/1/1/1/1/1/1 0 or 1 000-b3
2 IMAGE_IN_HD_POL 1/1/1/1/1/1/1/1/1 0 or 1 000-b2
3 IMAGE_IN_VD_POL 1/1/1/1/1/1/1/1/1 0 or 1 000-b1
4 IMAGE_IN_LPF_SEL 0/0/0/0/0/0/0/0/0 0 or 1 000-b0
5 IMAGE_OUT_CLK_POL 0/0/0/0/0/0/0/0/0 0 or 1 001-b5
6 IMAGE_OUT_HD_POL 0/0/0/0/0/0/0/0/0 0 or 1 001-b4
7 IMAGE_OUT_VD_POL 0/0/0/0/0/0/0/0/0 0 or 1 001-b3
Electrical Adjustments
No. Adjustment Item Initial Value Range Input source / Description
