22
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. If a part is missing,
call toll-free 1-800-999-3756. See the back cover of this manual for information about ordering replacement
parts.
Key No. Qty. Description Key No. Qty. Description
PART LIST—Model No. 831.283180 R0703A
1 1 Frame
2 1 Front Stabilizer
3 1 Frame Extension
4 1 Seat Carriage
5 1 Backrest Frame
6 1 Seat Frame
7 1 Rear Stabilizer Cover
8 1 Front Stabilizer Cover
9 1 Rear Stabilizer
10 1 Backrest
11 1 Left Handlebar
12 1 Seat
13 1 Upright
14 1 Upright Bushing
15 1 Right Handlebar
16 1 Console
17 1 Left Side Shield
18 1 Right Side Shield
19 1 Side Shield Cover
20 2 Seat Carriage Bushing
21 2 Small Hand Weight
22 2 Medium Hand Weight
23 2 Large Hand Weight
24 1 Left Pedal
25 1 Left Pedal Strap
26 1 Right Pedal
27 1 Right Pedal Strap
28 2 Adjustment Knob
29 1 Adjustment Pin
30 2 Wheel
31 1 Left Front Endcap
32 1 Right Front Endcap
33 2 Foot
34 1 Adjustment Motor
35 1 Upper Wire Harness
36 1 Lower Wire Harness
37 1 Flywheel
38 1 Magnet
39 1 Flywheel Axle
40 2 Flywheel Bearing
41 1 “C” Magnet
42 1 Left Crank Arm
43 1 Reed Switch/Wire
44 1 Crank Bearing Assembly
45 4 M5 Flat Washer
46 1 Adjustment Cable
47 1 Return Spring
48 2 M6 Nylon Locknut
49 2 Seat Bushing
50 1 Backrest Frame Endcap
51 1 1/2” x 70mm Button Bolt
52 1 1/2” Nylon Locknut
53 1 Belt
54 1 Pulley/Crank
55 1 M6 x 25mm Bolt
56 2 Flange Screw
57 1 Right Crank Arm
58 2 M6 Eyebolt
59 1 “U” Bracket
60 4 M6 Nut
61 5 M8 Nylon Locknut
62 2 Flywheel Washer
63 2 M10 Black Nylon Locknut
64 7 M6 x 16mm Screw
65 2 M10 x 112mm Carriage Bolt
66 2 M10 Zinc Nylon Locknut
67 1 “C” Magnet Bracket
68 2 M10 x 52mm Zinc Button Bolt
69 1 M6 x 50mm Screw
70 8 M5 x 7mm Screw
71 1 M6 Flat Washer
72 5 M4 x 25mm Screw
73 12 M4 x 16mm Screw
74 2 M10 x 45mm Button Screw
75 4 M4 x 38mm Round Head Screw
76 2 M8 x 39mm Button Bolt
77 2 Handlebar Collar
78 2 M5 Nut
79 1 M6 x 25.4mm Button Screw
80 2 M6 x 72mm Button Screw
81 4 M5 x 12mm Bolt
82 1 Reed Switch Clamp
83 4 M5 Nylon Locknut
84 2 M4 x 12mm Round Head Screw
85 2 M10 Zinc Split Washer
86 2 Foam Grip
87 1 M6 Large Washer
88 1 M8 x 14mm Button Screw
89 1 Water Bottle Holder
90 2 Handlebar Foam
91 2 M4 x 22mm Screw
92 1 M4 x 8mm Screw
93 2 Seat Frame Endcap
94 4 M8 x 12mm Button Screw
95 1 Handlebar Bracket
# 1 User’s Manual
# 3 Allen Wrench
