A S S E M B LY ST E P 9
PRE-ATTACHED SCREWS
CONSOLE
CONSOLE MAST
CONSOLE WIRES
NOTE: There is NO hardware bag for this step. All hardware is pre-installed.
A) Attach the CONSOLE MAST wires to the CONSOLE wires.
B) Carefully tuck the CONSOLE MAST wires into the CONSOLE MAST before attaching the CONSOLE.
DO NOT PINCH WIRES!
C) Attach CONSOLE to the CONSOLE MAST using the 4 PRE-ATTACHED SCREWS.
Connect POWER CORD to the POWER CORD SOCKET, located at front of the main frame. Connect
POWER CORD to a power outlet. Flip the switch to the ON position. After a “beep”, the CONSOLE will
turn on.
Y O U ’ R E FI N I S H E D !
B E F O R E Y O U B E G I N
Congratulations on choosing your elliptical! You’ve taken an important step in developing and sustaining
an exercise program! Your elliptical is a tremendously effective tool for achieving your personal fitness
goals. Regular use of your elliptical can improve the quality of your life in so many ways.
HERE ARE JUST A FEW OF THE HEALTH BENEFITS OF EXERCISE:
• Weight Loss
• A Healthier Heart
• Improved Muscle Tone
• Increased Daily Energy Levels
The key to reaping these benefits is to develop an exercise habit. Your new
elliptical will help you eliminate obstacles that prevent you from exercising.
Inclement weather and darkness won't interfere with your workout when you
use your elliptical in the comfort of your home. This guide provides you with
basic information for using and enjoying your new machine.
LOCATION OF THE ELLIPTICAL
Place the elliptical on a level surface. There should be 6 feet of clearance
behind the elliptical, 3 feet on each side and one foot in front for the power
cord (See diagram to the right). Do not place the elliptical in any area that
will block any vent or air openings. The elliptical should not be located in a
garage, covered patio, near water or outdoors.
GFFU
GFFU
GFFU
GPPU
