IN1606 Scaling Presentation Switcher • SIS Communication and Control 38
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Preset Commands
User presets
Recall preset
1*X2!. 1RprX2!] Recall user preset X2!.
Save preset
1*X2!, 1SprX2!]
Save the current picture controls.
Delete preset
EX1*X2!PRST} PrstX1*X2!] Clear user preset X2!.
User preset name
Write name
E1*X2!,X1$PNAM} Pnam1*X2!,X1$] Set user preset X2! name to X1$.
View name
E1*X2!PNAM} X1$] View the name of user preset X2!.
NOTE: To clear an user preset name, enter a single space character for X1$. This resets the user preset name
to the default value, “[User Preset XX].” This is valid only for existing presets.
Input presets
Recall preset
2*X2@. 2RprX2@] Recall input preset X2@.
Save preset
2*X2@, 2SprX2@]
See the table below for settings
saved on input presets.
Delete preset
EX2*X2@PRST} PrstX2*X2@] Clear input preset X2@.
Input preset name
Write name
E2*X2@,X1$PNAM} Pnam2*X2@,X1$] Set input preset X2@ name to X1$.
View name
E2*X2@PNAM} X1$] View the name of user preset X2@.
NOTE: To clear an input preset name, enter a single space character for X1$. This resets the input preset name
to the default value, “[Input Preset XXX].” This is valid only for existing presets.
Auto memories (per input)
Enable
EX!*1AMEM} AmemX!*1]
Enable Auto memory.
Disable
EX!*0AMEM} AmemX!*0]
Disable Auto memory.
Input preset availability
Query input preset
availability
51#
X(
1
X(
2
...X(
128
]
PreIX(
1
X(
2
...X(
128
] Verbose mode 2 and 3
Query user preset
availability
52*X!# X(
1
X(
2
...X(
16
]
PreUX!*X(
1
X(
2
...X(
16
] Verbose mode 2 and 3
NOTES:
X! = Input selection 1-6
X( = Enable or disable 0 = disabled or unassigned
1 = enabled or assigned
X1$ = Text label Up to 16 characters
X2! = User presets 1-16
X2@ = Input presets 1-128
Saved Settings for User Presets Saved Settings for Input Presets
Color Detail Input Type Contrast V Start Image H/V Position
Tint Preset Name Preset Name Brightness H Active Image H/V Size
Contrast Image H/V Position Audio Gain/Attenuation Detail V Active
Brightness Image H/V Size Color Total Pixels Phase
Tint H Start Film Mode
