Note: # indicates a non-illustrated part. Specifications are subject to change without notice. If a part is missing,
call toll-free 1-888-533-1333.
Key No. Qty. Description Key No. Qty. Description
PART LIST—Model No. 831.28622.0 R1107A
1 1 Frame
2 1 Upright
3 1 Left Side Shield
4 1 Right Side Shield
5 2 Handlebar Leg
6 1 Left Handlebar
7 2 M10 x 74mm Button Bolt
8 1 Right Handlebar
9 2 Stabilizer
10 2 M5 Nylon Locknut
11 1 Left Pedal Leg
12 1 Right Pedal Leg
13 1 Left Pedal
14 1 Right Pedal
15 2 Pedal Disc
16 2 Disc Crossbar
17 1 Flywheel
18 1 Side Shield Bracket
19 1 Drive Belt
20 2 Rear Endcap
21 2 Front Endcap
22 1 Belt Idler
23 1 Console
24 2 Handgrip
25 2 M6 Bolt Set
26 1 Pivot Axle
27 4 M8 x 52mm Button Screw
28 4 M8 Split Washer
29 1 Water Bottle Holder
30 2 Large Snap Ring
31 2 Large Bearing
32 1 Pedal Axle
33 7 M10 Nylon Locknut
34 4 M10 x 75mm Carriage Bolt
35 4 M10 Washer
36 2 M3 x 16mm Screw
37 2 Pedal Arm Bushing
38 5 M8 Nylon Locknut
39 2 Inside Pedal Arm Bushing
40 2 M10 x 27mm Patch Screw
41 2 M6 x 18mm Bolt
42 6 M5 x16mm Screw
43 4 M5 Washer
44 2 Handlebar Endcap
45 2 M10 Split Washer
46 2 Handlebar Cap
47 2 Handlebar Spacer
48 2 Frame Spacer
49 6 Small Handlebar Bushing
50 4 M8 x 45mm Button Bolt
51 4 M6 x 25mm Screw
52 7 M4 x 16mm Self-tapping Screw
53 1 Reed Switch/Wire
54 1 Cable Clamp
55 2 Handlebar Washer
56 2 M8 x 25mm Patch Screw
57 1 Flywheel Axle
58 1 Magnet
59 4 Console Screw
60 4 Large Handlebar Leg Bushing
61 2 5/16” x 25.4mm Hex Bolt
62 1 M10 x 60mm Button Bolt
63 2 M4 x 22mm Screw
64 4 M4 x 25mm Screw
65 1 M8 x 22mm Flat Head Screw
66 2 M6 Nylon Locknut
67 2 M5 x 14mm Self-tapping Screw
68 1 Extension Wire
69 2 Wave Washer
70 4 M6 x 28mm Screw
71 4 M8 Washer
72 1 Resistance Motor
73 1 Lower Wire Harness
74 2 Pedal Leg Endcap
75 1 Upright Endcap
76 2 Large Wave Washer
# 2 Hex Key
# 1 Grease
# 1 User’s Manual
