S3.45 Assembly and Maintenance Guide
page 47
1 2 3 4 5 6
4
Adjustments and
Maintenance
After the S3.45 is completely assembled, you must
check the Cables for proper tension. Obvious signs
that Cable problems exist include:
✔ The Cap Plate does not rest squarely on the top
weight of the Weight Stack.
✔ The Cable rubs the inside edges of the pulleys.
✔ Excess slack exists in the Cable.
CAUTION: Take the time to perform the following
steps. If the Cables do not have the proper tension,
you could void the Precor Limited Warranty.
1. Cable Adjustments
A. Place the Weight Pin in the Top Cap to ensure the
least Cable resistance.
B. To remove slack from the Cable, pull up on the
Chest Press Handlebars and adjust the cam
washer.
C. Lower the Chest Press Handlebars.
D. Check the weights. Move the Weight Pin to each
weight plate and Selector Stem location.
Adjustments and Maintenance
C
Chest Press Arms
B
Cam Washer
Top Cap
Weight
Weight
Pin
A
Top Weight
D
Weight
Pin
