Unpacking the 718e Low Impact Climber
All Precor products are thoroughly tested and inspected before shipment. The
718e Low Impact Climber is shipped in the following pieces:
• base
• upright support (long column)
• base column support (short column)
• resistance cylinders
• handrail console
• electronic console display
• hardware kit, Owner’s Manual, and limited warranty card (not shown in
Diagram 1)
718e
718e
USA
R
USA
R
USA
R
Resistance cylinders
Base
Diagram 1
Unpacking the climber
Upright support (long column)
Base column support
(short column)
Handrail consoles
Electronic console display
Unpack the climber and place all the pieces on the floor. For help in identifying
the various pieces, refer to Diagram 1. The packet containing the hardware kit,
Owner’s Manual, and limited warranty card is not shown.
Important: Do not pinch or crimp the reed switch cable during the unpacking
and assembly process. The rope attached to the 718e upright assembly is used
to install the reed switch cable. Do not remove the rope from the 718e upright
assembly at this time. Do not cut the wire ties holding the stair arms to the
upright support.
