8-42 CHASSIS
• Remove the dust seal with the special tool.
09913-50121: Oil seal remover
• Remove the dust seal with the special tool.
09913-50121: Oil seal remover
INSPECTION AND DISASSEMBLY
TIRE INSPECTION (2-x and 8-85)
WHEEL INSPECTION (8-85)
REAR AXLE
• Using a dial gauge, check the rear axle for runout.
• If the runout exceeds the limit, replace the rear axle.
Axle shaft runout: Service Limit: 0.25 mm (0.010 in)
09900-20607: Dial gauge (1/100 mm)
09900-20701: Magnetic stand
09900-21304: V-block set (100 mm)
WHEEL DAMPER
• Inspect the damper for wear and damage.
• Replace the damper if there is anything unusual.
The removed dust seal must be replaced with a new
one.
The removed dust seal must be replaced with a new
one.
