PDS • User’s Guide 115
7. PDS-902 3G Enhancements
Input Sizing Adjustments
1. Press and hold a PIP button. Select an input source. The pended input source
button blinks.
2. Press TAKE to transition to the selected source through black.
A pended source overrides the source on Program.
After you press TAKE, there are no pending sources. PIP buttons are lit solid for
active PIP sources.
3. Repeat steps 1 and 2 to select and transition the second PIP.
To cancel a pended source, press and hold the appropriate PIP button.
If you select an input source instead of a PIP, that source pends for both PIPs, which can
be transitioned on the next Take.
fåéìí=páòáåÖ=^ÇàìëíãÉåíë
The PDS supports adjusting the input sizing to one of three selections: Native, Zoom, or
Stretch. You can save any sizing selection to any input. Select Input > Sizing Adjust and
choose one of the following options:
• Native. The input image is displayed at its original resolution. Native is the default
setting. In the example below, a 4:3 input image is displayed on a 16:9 output.
Figure 7-7. An image with native 4:3 input aspect ratio shown in16:9 output aspect ratio
• Zoom. The input fills the output display such that the original aspect ratio is
maintained and no background bars are present. In this mode, horizontal or
