7. PDS-902 3G Enhancements
Output Display Modes
display one or both PIPs on the Preview output, and to transition one or both to Program.
From a factory reset or coming from another output display mode, the PIPs are placed in
one of two predefined default positions, as shown in the following figure.
Figure 7-4. Default positioning for PIPs
When the output resolution is 4:3 or 5:4 aspect ratio, the PIPs are displayed in a Top/
Bottom configuration. Otherwise, the PIPs are displayed in a Left/Right configuration.
The PIP1 button is assigned to the left or top PIP. PIP2 is assigned to the right or bottom
PIP.
mfm=^ÇàìëíãÉåíë
The PIP Adjustment Menu becomes available in the Setup Menu when the output display
mode is PIP, and you press a PIP button. On this menu, you select a PIP and then set
various properties for it, including the background color, horizontal and vertical sizing, and
positioning. The Units option on this menu lets you set the values in either pixels or
percentages. You can save the PIP configuration and recall it for later use. Or you can reset
the PIP to its default settings.
Figure 7-5. PIP Adjustment Menu
PIP Adjustment
> PIP 1
Pgm Background Custom
Background Color >>
Size H/V >>
Size H 1280
Size V 960
Position H +0
Position V +0
Fullscreen
Units Pixel
Save Config >>
Recall Config >>
Reset
