21
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. If a part is missing,
call
toll-free 1-888-533-1333.
See the back cover of this manual for information about ordering replacement
parts.
PART LIST—Model No. 831.215220 R1104A
1 1 Frame
2 1 Upright
3 2 Handlebar
4 1 Console
5 1 “C” Magnet Bracket
6 1 Flywheel Axle
7 2 M6 Nut
8 6 M6 x 16mm Button Screw
9 1 Seat
10 1 Seat Carriage Assembly
11 1 Seat Bracket
12 1 Left Front Endcap
13 1 Right Front Endcap
14 2 Rear Stabilizer Endcap
15 1 Front Stabilizer
16 1 Rear Stabilizer
17 2 Wheel
18 1 Right Pedal Strap
19 2 Leveling Foot
20 1 Leg
21 1 Right Pedal
22 1 Left Pedal
23 1 Book Holder
24 2 Handlebar Endcap
25 1 Left Pedal Strap
26 1 Left Side Shield
27 1 Right Side Shield
28 2 Foam Grip
29 1 Pulley
30 1 Magnet
31 1 Backrest
32 2 Flywheel Washer
33 1 Crank Bearing Set
34 1 Flywheel
35 1 “C” Magnet
36 1 Resistance Cable Assembly
37 1 Spring
38
1
Resistance Motor
39 1 Right Rail Cover
40
9 M8 x 19mm Button Screw
41 8 M4 x 12mm Screw
42 1 Upper Wire Harness
43 1 Lower Wire Harness
44 1 Left Rail Cover
45 1 Clamp
46 1 Reed Switch/Wire
47 1 Drive Belt
48 1 Flywheel Cover
49 6 M8 Nylon Locknut
50 1 Frame Rail Endcap
51 2 Bumper
52 1 Frame Rail
53 1 Right Belt Cover
54 1 Left Belt Cover
55 13 M8 Split Washer
56 2 M4 x 20mm Screw
57 10 M4 x 16mm Screw
58 4 M8 x 38mm Button Bolt
59 4 M4 Washer
60 4 M4 x 25mm Screw
61 4 M8 x 16mm Button Screw
62 6 M4 x 10mm Screw
63 3 M6 x 20mm Button Screw
64 8 Small Snap Ring
65 8 Carriage Wheel
66 5 M6 Washer
67 7 M4 x 38mm Screw
68 4 M4 x 15mm Flange Bolt
69 2 Eyebolt
70 2 Flywheel Bearing
71 4 M4 Nylon Locknut
72 4 M10 Nylon Locknut
73 1 Flywheel Bracket
74 4 M6 Nylon Locknut
75 2 M6 x72mm Button Screw
76 4 M10 x 112mm Carriage Bolt
77 1 Stop Bolt
78
2
Seat Carriage Endcap
# 1 Allen Wrench
#
1 User’s Manual
Key No. Qty. Description Key No. Qty. Description
