HOW T
O USE THE MANUAL MODE
T
urn on the console.
To turn on the con-
sole, press the
On/Reset button
or begin pedaling.
Note: If there are
sheets of clear
plastic on the face
of the console, remove the plastic.
Select the manual mode.
When the power is
turned on, the
manual mode will
be selected. If you
have selected a
program or the
iFIT.com mode,
reselect the manual mode by pressing the
Program button repeatedly until no indicators are
lit.
Begin pedaling and change the resistance of
the pedals as desired.
As you pedal,
change the resis-
tance of the ped-
als by pressing
the Resistance
buttons. There are
ten resistance lev-
els—level 10 is the most challenging. Note: After
the buttons are pressed, it will take a moment for
the pedals to reach the selected resistance level.
Monitor your progress with the display.
The upper part of
the display will
show the distance
you have pedaled
and the approxi-
mate number of
calories you have
burned. The display will change from one number
to the other every few seconds. The upper part of
the display will also show your heart rate when
you use the handgrip pulse sensor (see step 5 on
page 11).
The center of the
display will show
the elapsed time,
your pedaling pace
in minutes per mile,
and the approxi-
mate number of
grams of carbs you have burned. The display will
change from one number to the next every few
seconds. Note: When a program is selected
(except for the self select program), the display
will show the time remaining in the program
instead of the elapsed time.
The lower part of
the display will
show your pedaling
pace in revolutions
per minute (RPM),
your pedaling
speed, and the
resistance level of the pedals. The display will
change from one number to the next every few
seconds.
To reset the display, press the On/Reset button.
Note: The console
can show speed
and distance in
either miles or
kilometers. The
letters MPH or
KM/H will appear in
the lower part of the display to show which unit of
measurement is selected. To change the unit of
measurement, first hold down the Program button
for a few seconds. An E (for English) or an M (for
metric) will appear in the lower part of the display.
Press the Resistance + button to change the unit
of measurement. Note: When the batteries are
replaced, it may be necessary to reselect the
desired unit of measurement.
While you are
selecting a unit of
measurement, you
can also select a
backlight mode.
The “On” mode
keeps the backlight
on while the console is on. The “Off” mode turns
the backlight off. To conserve the batteries, the
“Auto” mode keeps the backlight on only while
you are exercising.
Press the Resistance – button
to change the backlight mode
if desired
.
Then,
press the On/Reset button.
4
3
2
1
On/Reset
Button
