9
8
8. Orient the Upright (4) assembly and the Pivot
Cover (12) as shown.
Slide the Pivot Cover (12) upward to the
Handlebar (5). Tip: Bend and flex the Pivot
Cover slightly to slide it over the Handlebar.
Attach the Pivot Cover (12) to the Handlebar (5)
with four M4 x 16mm Screws (90).
Next, pivot the Handlebar (5) until the hole in
the Handlebar is aligned with an adjustment
hole in the Upright (4).
Tighten an Adjustment Knob (27) into the
Handlebar (5) and into an adjustment hole in
the Upright (4). Make sure that the
Adjustment Knob is engaged in one of the
adjustment holes.
4
12
90
90
90
27
Hole
Adjustment
Holes
5
7
90
90
7. While another person holds the Console (13)
near the Handlebar (5), connect the wires on
the Console to the Extension Wire (59) and the
P
ulse Wire (61).
I
nsert the excess wire downward into the
Handlebar (5) or upward into the Console (13).
Tip: Avoid pinching the wires. Attach the
Console (13) to the Handlebar (5) with four M4
x 16mm Screws (90).
Avoid pinching
the wires
13
61
59
5
