22
1
1 Frame
21Front Stabilizer
31Rear Stabilizer
41Upright
51Handlebar
6 1 Seat Post
71Front Shield Cover
81Top Shield Cover
91Rear Shield Cover
10 1 Right Shield
11 1 Left Shield
12 1 Pivot Cover
13 1 Console
14 1 Right Pad
15 1 Left Pad
16 1 Pulse Sensor
17 2 Pedal Disc
18 2 Disc Cover
19 1 Right Crank Arm
20 1 Left Crank Arm
21 1 Right Pedal/Strap
22 1 Left Pedal/Strap
23 1 Seat
24 1 Seat Carriage
25 2 Seat Post Cap
26 1 Seat Adjustment Knob
27 2 Adjustment Knob
28 1 Seat Post Sleeve
29 2 Leveling Knob
30 1 Seat Bracket
31 2 Leveling Foot
32 2 Rear Stabilizer Cap
33 1 Right Stabilizer Cap
34 1 Left Stabilizer Cap
35 2 Wheel
36 2 Foot
37 2 Foam Grip
38 1 Pulley
39 1 Crank
40 2 Crank Bearing
41 2 Snap Ring
42 1 Flywheel
43 2 M8 Washer
44 1 Flywheel Axle
45 1 Idler
46 1 Motor Bracket
47 1 Resistance Motor
48 1 Resistance Disc
4
9 1 Resistance Arm
50 1 M6 x 70mm Bolt Set
51 1 M6 x 60mm Bolt Set
52 1 Arm Lock
53 1 C-magnet
54 1 Drive Belt
55 2 Magnet
56 1 Clamp
57 1 Reed Switch/Wire
58 1 Wire Harness
59 1 Extension Wire
60 2 Wire Clamp
61 1 Pulse Wire
62 2 M4 x 25mm Screw
63 2 M4 x 12.7mm Flange Screw
64 1 Audio Cable
65 3 M8 x 17mm Flat Head Screw
66 2 Handlebar Pivot Bushing
67 6 M4 x 19mm Flat Head Screw
68 2 Crank Cap
69 2 Upright Pivot Bushing
70 2 5/16" Flange Screw
71 4 M8 x 20mm Button Bolt
72 8 M8 Locknut
73 2 M8 Jam Nut
74 4 M8 x 20mm Patch Screw
75 12 M8 Split Washer
76 4 M10 x 95mm Patch Screw
77 1 M6 x 65mm Hex Screw
78 1 M6 Locknut
79 4 M4 x 12mm Flange Screw
80 2 M6 x 8mm Hex Screw
81 1 M5 Washer
82 1 M5 x 7mm Screw
83 1 M6 x 14.67mm Shoulder Screw
84 1 M6 Washer
85 1 M6 x 20mm Hex Screw
86 1 M10 x 50mm Hex Screw
87 1 M3.5 x 12mm Screw
88 1 M4 x 12.7mm Bright Screw
89 14 M4 x 19mm Screw
90 10 M4 x 16mm Screw
91 2 M4 x 5mm Bright Screw
92 2 Handlebar Cap
*–Assembly Tool
*–Grease Packet
*–Userʼs Manual
Key No. Qty. Description Key No. Qty. Description
PART LIST—Model No. PFEVEX74010.0 R
0910A
Note: Specifications are subject to change without notice. For information about ordering replacement parts, see
the back cover of this manual. *These parts are not illustrated.
