MOUNTING
The 4-12x80 can be mounted utilizing 40mm rings.
The 2-6x65 can be mounted utilizing 42mm rings.
CAUTION: Be sure gun is not loaded. Use safe gun han-
dling procedures at all times.
FOCUSING
While holding the scope about four inches from your
eye, quickly glance through the eyepiece at a featureless,
flatly lit bright area such as a wall or the sky.
CAUTION: Viewing the sun can cause serious eye injury,
never look at the sun with this product or even the naked
eye.
If the reticle is not sharply defined instantly, turn the
eyepiece (either direction) a few turns. Quickly glance
through the scope again. If the focus has improved, but is
still not perfect, continue focusing. If the focus condition
became worse, turn it the opposite way.
PRE-ZEROING
Pre-zeroing is recommended and can be done with a scope guide or bore sight. These
items have their own instructions.
CAUTION: Be sure gun is not loaded. Use safe gun handling procedures at all times.
ZEROING
CAUTION: All shooting should be done at an approved range or other safe area. Eye and
ear protection is recommended.
DANGER
If you used a bore-obstructing device, remove it before proceeding. If the barrel
has-been drilled for a mount, check that the screws do not protrude into the bore.
Do not fire live or even blank ammunition with an obstructed barrel. An obstruction
can cause serious damage to the gun and possible personal injury to yourself and
others nearby.
From a steady rest position, fire three rounds at a 100 yard target for 2-6x65 and 200
yard target for 4-12x80. Observe bullet strike on target and adjust windage and elevation
screws as needed to correct aim. You will need to remove the dust caps from the top of
the windage and elevation adjustments to do this.
NOTE: Each click of adjustment changes bullet strike by the amount shown on the chart
below.
WINDAGE / ELEVATION
(inches of movement per click)
When you have finished zeroing, replace windage
and elevation dust caps.
50 Yards-1/16”
100 Yards-1/8”
200 Yards-1/4”
300 Yards-3/8”
±5 Diopter
