Diagram 3 - Ladder Diagram - PRO 35 III Diesel and PRO 65 III Diesel, 182121
Component Designators
DESIGNATOR DEVICE FUNCTION
ALT ALTERNATOR BATTERY CHARGING
CB CIRCUIT BREAKER MAIN POWER
CR1 CONTROL RELAY POWER TO FUSE BLOCK
CR2 CONTROL RELAY ENGINE STARTER
CR3 CONTROL RELAY ENGINE TEMP SHUTDOWN
F1 FUSE, 5A ALTERNATOR EXCITATION
F2 FUSE, 5A ENGINE GAUGES
F3 FUSE, 10A FUEL SOLENOID CIRCUIT
F4 FUSE, 5A RAISE-LOWER CIRCUIT
F5 FUSE, 10A WATER PUMP (OPTIONAL)
F6 FUSE, 10A LIGHT KIT (OPTIONAL)
GA1 GAUGE ENGINE TACHOMETER & HOURMETER
GA2 GAUGE ENGINE OIL PRESSURE
GA3 GAUGE BATTERY VOLTMETER
M1 MOTOR ENGINE STARTER
M2 MOTOR HYDRAULIC PUMP
M3 MOTOR WATER PUMP (OPTIONAL)
P1 PLUG CONNECTOR COWL TO ENGINE HARNESS
SV1 SOLENOID VALVE RAISE-LOWER SAW
SW1 SWITCH (KEY) ENGINE, OFF-RUN-START
SW2 SWITCH (PUSH-PULL) EMERGENCY STOP
SW3 SWITCH (ROCKER) WATER SWITCH OFF
SW4 SWITCH (ROCKER) LIFT SWITCH, RAISE-OFF-LOWER
SW5 SWITCH (ROCKER) WATER PUMP, ON-OFF (OPTIONAL)
