PRO 35 III 20HP ELECTRIC SPECIFICATIONS
MODEL NO: 26S/230V 26S/460V 30S/230V 30S/460V 30S/575V
Item Number: C80166 C80165 C80168 C80167 C80169
Item No. N/A N/A N/A N/A N/A
w/Water Pump:
STANDARD SAW FEATURES
Blade Guard Capacity: in (mm): 26" (650) 26" (650) 30" (750) 30" (750) 30" (750)
Bladeshaft RPM: 1750 1750 1420 1420 1420
Max. Depth Of Cut: 10-3/4" 10-3/4" 12-1/2" 12-1/2" 12-1/2"
(27.3 cm) (27.3 cm) (31.8 cm) (31.8 cm) (31.8 cm)
Arbor Size: 1" (25.4mm) with drive pin, blade can be mounted on either side of shaft (two drive pins)
Blade Shaft: 1-7/16" (36.5mm) diameter
Blade Shaft Bearings: Dual self-aligning pillow block ball bearings
Blade Shaft Drive: Six(6) 3VX V-Belts
Blade Control: Electro-hydraulic pump raises and lowers blade; positive depth stop, cutting depth
indicator. Quick-Lift blade raising and lowering button on the speed control lever.
Blade Coolant: Water; Zinc plated dual multiple-jet water spray tubes; Water supply connector located at
left rear of saw; Separate water control valves on each side of the saw.
Axles: Front 1" (25.4mm) diameter
Rear 1" (25.4mm) diameter
Wheels: Front 6" x 2" x 1" (152 x 51 x 25.4mm); roller bearings, solid polyurethane tires, neoprene grease
seals, pressure lubrication fittings provided
Rear 8" x 2" x 1" (203 x 51 x 25.4mm); keyway; solid rubber tread; mounted and keyed on axle
shaft
Transmission: Hydrostatic Transmission with sealed gearbox and single chain final drive, neutral and
neutral safety start switch, parking brake, single control handle for neutral and
forward/stop/reverse.
Speed Infinite speed 0 to 220 FPM forward and reverse
Brake: Spring applied; Hydraulic pressure release; Caliper and Disc brakes.
Chassis: Heavy-Duty, rigid, box and channel section construction
Weight - lb. (kg)
Crated: 933 (423)
Uncrated: 860 (390)
Add for: Pump 10 (4.5)
Deluxe Spotlight 7 (3)
