Using the
Extron Product
Configuration
Software
The Extron PVS 405D Product Configuration Software (PCS) offers another way to control
the PVS 405D via USB or rear panel RS‑232 connection, in addition to using the SIS
commands.
This section describes installation, communication, and control. The topics include:
• Installing the Software
• Starting the PVS 405D Product Configuration Software
• Using the PVS 405D Product Configuration Software — Menus
• Using the PVS 405D Product Configuration Software — Pages
The graphical interface includes the same functions as those on the device front panel
with additional features that are only available through the software.
The Configuration Software is compatible with Windows XP and Windows 7, and
Windows 8. The software program is included on the Extron software DVD. Updates can
be downloaded from the Extron web site (www.extron.com).
Installing the Software
The PCS software can be downloaded from the Extron web site and installed onto the
hard drive of a connected PC.
Installation from the Website
1. On the Extron web site (www.extron.com), select the Download tab. The Download
Center screen appears.
2. On the Download Center screen, select PCS within Software menu from the left
side‑bar.
3. Click Download Now.
4. Follow the on‑screen instructions to download the program to your PC.
