Replacing Instrument Assemblies
Replacing Instrument Assemblies
This section provides step-by-step procedures to remove and replace the
major instrument assemblies. These include the following procedures:
To remove the instrument cover 5-27
To replace the A2 Source assembly 5-28
To replace the A5 Laser Driver Board Assembly 5-30
To route the rear-panel BNC modulation cable 5-32
To replace line filter assembly FL1 5-33
To replace a cable clip 5-34
