To set up the channel match test
Performance Test and Operation Verification
This test verifies that the Agilent 35670A meets its cross channel amplitude and
cross channel phase specification. In this test, the Agilent 35670A’s source outputs
an identical signal to all channels. The Agilent 35670A measures the amplitude
and phase of the signal and compares the values measured on one channel to the
values measured on another channel.
1 2ch
1 4ch
Agilent 35670A Verifying Specifications
To set up the channel match test
3-21
