To adjust filter flatness
This procedure adjusts the anti-alias filter on the A1/A2 Input assemblies. The
standard two channel analyzer has one A1 Input assembly. The optional four channel
analyzer has two A2 Input assemblies: channel 1 and 3 are routed to the A2 Input
assembly in the lower slot and channel 2 and 4 are routed to the A2 Input assembly in
the upper slot.
Equipment Required: None
Agilent 35670A Adjusting the Analyzer
To adjust filter flatness
5-17
