To remove rear panel
1 Remove cover (see ‘’To remove cover’’). 2 Using a T-15 torx driver, remove the seven
screws from the rear panel. Pull the rear panel
straight off.
3 Disconnect the ribbon cable and the coaxial
cable from the A10 Rear Panel assembly.
Agilent 35670A Replacing Assemblies
To remove rear panel
6-7
