14
Automatically scans each function of TIME, SPEED, DISTANCE, CALORIES, ODOMETER,
RPM, and PULSE in sequence with change every six seconds. Press and release the
MODE button until the arrow points to “SCAN”.
Displays the time from one second up to 99:59 minutes.
Displays the current speed from zero to 999.9 miles per hour.
Displays the distance from zero to 999.9 miles.
Displays the calorie consumption from zero to 999.9 Kcal.
The calorie readout is an estimate for an average user. It should be used only as a
comparison between workouts on this unit.
Displays the total accumulated distance you have traveled from zero to 9999 miles. The
total accumulated distance is retained when the meter is turned off.
Displays crank RPM (revolutions per minute) from zero to 9999 rpm.
Displays your pulse rate in beats per minute. To display pulse, select the PULSE mode
and grasp the pulse sensors on the handlebar, one in each hand. The heart symbol
“ “ will begin ashing when the meter senses your pulse. Your pulse will be displayed
approximately ve (5) seconds after the heart symbol is displayed. If the heart symbol
does not appear, relax your grip or change your grip on the pulse sensors.
FUNCTIONS:
SCAN:
TIME:
SPEED:
DISTANCE:
CALORIES:
ODOMETER:
RPM:
PULSE:
Pedal movement or push the MODE button.
Automatic shut off after four minutes of
inactivity.
POWER OFF :
POWER ON :
MODE BUTTON:
Press to select display functions, include SCAN, TIME, SPEED,
DISTANCE, CALORIES, ODOMETER, RPM, and PULSE.
Press and hold for three seconds to reset all functions to zero,
except ODOMETER.
The meter will shut off automatically after four minutes of inactivity. All function values will
be reset to zero, except ODOMETER. The ODOMETER will be reset to zero after batteries
are removed for battery replacement or storage of the unit.
NOTE:
OPERATIONAL INSTRUCTIONS
USING THE FITNESS METER
1. Open the Battery Door on the back of the meter.
2. The meter operates with two AA batteries, the batteries are not
included. Refer to the illustration to install or replace the batteries.
1. Do not mix a new battery with an old battery.
2. Use the same type of battery. Do not mix an alkaline battery with
another type of battery.
3. Rechargeable batteries are not recommended.
NOTE:
HOW TO INSTALL AND REPLACE BATTERIES:
AA Batteries
MODE
QUICK
START
SCAN
TIME
SPEED
DIST
CAL
ODOMETER
RPM
PULSE
