PART LIST—Model No. RBTL69908.0 R
0208A
Key No. Qty. Description Key No. Qty. Description
1
19 M4.2 x 19mm Screw
2 4 M4.2 x 25mm Screw
3 2 M4 x 20mm Screw
4 2 M10 x 50mm Bolt
5 4 M10 x 96mm Bolt
6 4 M8 x 25mm Bolt
7 1 3/8" Star Washer
8 4 M10 Star Washer
9 2 M8 Nut
10 4 M8 Star Washer
11 5 M4.2 x 13mm Belly Pan Screw
12 15 M4.2 x 16mm Screw
13 3 M4.2 x 19mm Hood Screw
14
2 M8 x 35mm Screw
15 2 M8 x 90mm Screw
16 2 M10 x 30mm Bolt
17 2 M6 x 70mm Bolt
18 1 3/8" x 1 3/4" Bolt
19 1 3/8" x 1 1/2" Bolt
20 2 3/8" x 1" Bolt
21 1 M6 x 45mm Bolt
22 9 M4.2 x 13mm Ground Screw
23 8 M5.5 x 25mm Screw
24 2 1/4" x 3/8" Bolt
25 2 3/8" x 3/4" Bolt
26 1 3/8" x 4" Bolt
27 1 #8 x 1/2" Ground Screw
28 4 M4.2 x 13mm Screw
29 2 M6 Lock Washer
30 2 M6 Washer
31 3 3/8" Jamnut
32
2
3/8" Motor Nut
33 4 M10 Nut
34 1 6mm Hex Key
35
2
Platform Cushion
36 2 3/8" Locknut
37 3 Hood Clip
38
4 Cage Nut
39 1 Left Foot Rail
40 1 Console Ground Wire
41 2 Belt Guide
42
1
Magnet
43 1 Motor Belt
44 1 Front Roller/Pulley
45 1 Walking Belt
46 1 Walking Platform
47 1 Right Foot Rail
48 1 Frame
49 1 Warning Decal
50 2 Rear Roller Bracket Plate
5
1 1 Left Foot
52 1 Right Foot
53 1 Hood
54 1 Reed Switch
55 1 Reed Switch Clip
56 2 Frame Spacer
57 1 Lift Frame/Roller Ground Wire
58 1 Incline Motor
59 2 Rear Roller Bracket
60 1 Motor
61 1 Motor Bracket
62 3 Lift Frame Cable Tie
63 1 Lift Frame
64
2 M8 Flange Nut
65 1 Power Cord
66 1 Controller
67 1 Power Cord Grommet
68 1 Reset/Off Circuit Breaker
69 1 Belly Pan
70 2 M4.2 Star Washer
71 1 Latch Housing
72 1 Latch Pin Assembly
73 1 Left Upright
74 1 Left Bottom Pulse Plate
75 1 Audio Wire
76 2 #10 x 1" Tek Screw
77 1 Upright Wire
78 1 Right Upright
79 4 Bolt Spacer
80 1 Right Upright Spacer
81 4 Base Pad
82
2
Base Endcap
83 1 Left Upright Spacer
84 2 Caution Decal
85
1
Base
86 2 Wheel
87 1 Console
88
1 Console Base
89 1 Left Handrail
90 1 Right Handrail
91 2 Handrail Endcap, Lower
92
2
Cable Tie
93 1 Key/Clip
94 2 Releasable Tie
95 10 8" Cable Tie
96 1 Left Top Pulse Plate
97 1 Filter Wire
98 1 15 1/2" Cable Tie
99 1 Lift Motor Spacer
100 1 Rear Roller
To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual.
