EFX 5.21/ 5.23 Elliptical Fitness Crosstrainer Assembly Guide 8
Before exercising, make sure the EFX is level and does not wobble from
side to side.
Important: If the EFX is placed on a slightly uneven surface, turning the
leveling pads can help, but will not compensate for extremely uneven
surfaces.
1. Kneel by the side of the stabilizer and lift the base slightly so you can
access the levelers.
2. Rotate the levelers as needed.
3. When the EFX is level, fully tighten the lock nut and lower the EFX to the
floor.
Connect the power cord.
CAUTION: Use the supplied and appropriate power cord. Do not remove
or otherwise bypass the 3-prong plug with an adapter in order to use a
non-grounded outlet. Do not plug the EFX into a power transformer in an
attempt to adjust the voltage requirements. Failure to follow these
instructions might damage the unit and will void the Precor Limited
Warranty. If an appropriate cord for your location was not included with
your EFX, please contact your Precor dealer for the proper Precor power
cord. For more information on authorized Precor dealers in your area,
please contact Customer Support at www.Precor.com.
1. Insert the power plug connector into its receptacle at the rear of the unit.
2. Plug the other end into a grounded outlet so you can maintain a
consistent power source without overloading any other circuitry. Be sure
to use the appropriate voltage. Refer to Grounding Instructions in the
owner’s manual.
Turn the unit On.
Use the power switch to turn the unit On. Check that the Precor banner
appears on the display. If the display remains blank, cycle the power. If the
display continues to remain blank, check the cable connections.
Important: Make sure the locking pin is removed and stored before you
begin exercising.
