10
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the user’s manual for information about ordering replacement parts.
Key No. Qty. Description Key No. Qty. Description
1
1 Outer Frame
2 1 Inner Frame
3 1 Outer Frame Cover
4 1 Inner Frame Cover
5 1 Carriage Frame
6 1 Carriage
7 2 Headrest Frame
8 4 25mm Round Inner Cap
9 1 Headrest
10 2 Shoulder Block
11 2 Carriage Tube
12 2 Pulley Tube
13 2 Wheel Leg
14 3 Cap Leg
15 3 50mm Round Outer Cap
16 4 75mm Square Inner Cap
17 1 Adjustment Knob
18 1 Adjustment Spacer
19 2 Wheel
20 4 Wheel Spacer
21 2 Resistance Bracket
22 4 Resistance Cord
23 2 Nylon Rope
24 2 Handle
25 2 Small Carriage Wheel
26 2 Pulley Housing
27 2 Pulley
28 2 Rope Grip
2
9 2 Grip Base
30 12 Bearing
31 2 Rope Storage Knob
32 1 Foot Bar
33 1 Foot Bar Cover
34 2 M6 x 45mm Screw
35 2 Inner Frame Cap
36 12 M6 x 18mm Screw
37 2 M4 x 20mm Screw
38 2 M4 x 16mm Screw
39 4 M8 x 84mm Bolt
40 2 M4 x 40mm Screw
41 1 M10 x 50mm Carriage Bolt
42 2 M10 x 65mm Bolt
43 2 M10 Nylon Locknut
44 8 M8 Nylon Locknut
45 4 M10 Washer
46 2 M8 x 36mm Bolt
47 2 M6 x 61mm Screw
48 2 Large Carriage Wheel
49 2 Carriage Plate
50 4 M6 x 15mm Screw
51 1 Left Eyebolt/Pin
52 1 Right Eyebolt/Pin
53 4 M8 Washer
# 1 User’s Manual
# 1 Exercise Guide
# 1 Video
PART LIST—Model No. NTCCBE19520 R0602B
