Assembly
9
Step 5
Insert Front Adjustable Frame (5) into the top of the Adjustable Frame (3). Pull the rope down and hook the
end of the spring onto the Hex Bolt M6*48mm (33) as shown in Figure 5b.
Figure 5a
Figure 5b
